Insulated Sandwich Wall Siding Panels
Aluminum sandwich panel is composed of three parts, the surface is color coated aluminum zinc magnesium steel plate, the core material of middle layer is special fireproof treatment hard high density polyurethane foam insulation layer, the bottom material is aluminum foil anti-corrosion layer.
Insulated sandwich wall siding panels
Product introduction
Insulated sandwich wall siding panels is a new type of environmentally friendly building material that has become very popular in recent years. The surface is a decorative panel metal plate with a colorful embossed pattern. The insulation layer of the rigid high-density polyurethane insulation section adopts a flame retardant solution, and the bottom edge is an aluminum platinum protective layer. It has its own advantages in the fields of thermal insulation, waterproof and flame retardant, sound insulation and so on. Generous and durable features have become the new favorite of contractors and customers.
Product Specification
|
Thickness |
14mm/16mm/20mm |
Fire resistance level |
B1/B2 |
|
Width |
383mm |
Size tolerance |
-/+2mm |
|
Length |
2m-6m |
Tensile bond strength |
0.17MPA |
|
Surface steel |
Galvalume,C type |
Wind load value |
9KPA |
|
Steel alloy composition |
Aluminum 55%,Zinc 43.5%,Silicon1.5%,ect |
Package |
10pieces/carton 8pieces/carton |
|
Steel coating |
HDP>30um |
Package Size |
4010mm*41mm*170mm(10pieces/carton) 4010mm*41mm*138mm(8 pieces/carton) |
|
Core material |
Polyurethane,40kg/m3 |
OEM |
Logo and panel size |
|
Thickness of bottom material |
0.026mm |
Container load |
20GP:1600sqm(panel length 1.82m) 40HC/HQ:3800sqm(panel length 3.8m) |
|
Closed cell rate |
90%-95% |
After-sale Service |
Online training,Online technical support |
|
Water absorption |
≤3% |
Port |
QINGDAO |
|
Panel weight |
3.5-3.7kgm2 |
Payment |
T/T,L/C |
|
R-VALUE |
0.55㎡*k/w |
Brand |
DIBAIER |
|
Heat conductivity |
0.024w/m*k(in theory) |
Dimensional stability |
≤1.5% |
|
Density |
40-60(kg/m3) |
Room temperature |
-196℃+120℃ |
|
Compressive strength |
200-270(kpa) |
Oxygen index |
≥26% |
|
Impact strength |
6.1J |
|
|
Product advantage
1. LIGHT-WEIGHT
Lightweight, novel and beautiful. Generally, the weight is 10kg/m2~14kg/m2, which is equivalent to 1/30 of the brick wall. Bright color on the surface, no need surface decoration.
2. EARTHQUAKE PROOF
Good strength, rigidity, stability, impact resistance, earthquake resistance, corrosion resistance and atmospheric resistance. Can be used to maintain the structure and bear the load. Structure, general houses don't use beams and columns.
3. SOUND INSUALTION AND HEAT INSULATION
Excellent heat preservation, heat insulation and sound insulation performance. In terms of anti-condensation performance, 35mm thick polyurethane board is equivalent to 1130mm red brick wall.
4.HIGH DECORATION
In order to give customers more decoration choices, aluminum sandwich panel have more than 100 kinds of relief patterns and color collocation composition, give higher architectural planning and design to give full play to the interior space. The practical effect of luxurious and beautiful decoration makes the construction show taste.
Product Accessories
Product accessories are mainly the same material accessories and aluminum alloy accessories .
How to install decorative insulation sandwich panels (DIY)?
Step 1: calculate the number of decorative siding needed
First measure the area of the wall to be decorated and calculate the number of panels. The effective width of the wallboard is 38.3cm, and the number of wallboards required can be known by calculating the wall area. At the same time, because of the fixed size of the board, some material waste rate needs to be added to ensure sufficient material.
Step 2: Calculate the type and length of the accessories used for the wall panel
Before installing insulation panels, you need to decide how the panels will connect. You can use the starting piece, the middle joint piece, and the closing piece of this kind of wallboard for connection. These accessories will not affect the decorative effect of the wallboard, and at the same time can ensure that the wallboard is very stable during installation. Plan the plug-in method and location of accessories. And mark it with a pen.
Step 3: Prepare the Wall Panels
Before installation, the insulation panels need to be prepared. Cut the insulation panels to size with a hand saw and leave to dry to ensure that the bonding area is dry and smooth.
Step 4 Prepare accessories
Cut the accessories according to the length of the wall with a hand saw.
Product Transportation
We usually ship our products by sea
FAQ
Q: Can we use our own logo?
A: Yes, we can print your private logo according to your request.
Q: How long is your delivery time?
A: The general delivery time is 10-15 days after receiving your order confirmation. Anther, if we have the goods in stock, it will only take 5-10 days.
Q: Which payment form you can accept?
A: T/T, L/C, PayPal etc. We accept any convenient and swift payment term.
Q: Which shipping way can you provide?
A: We can provide shipping by sea
Q: What’s your after-sale service?
A: Our quality warranty period is 5 years. Any aluminum sandwich panel’s quality problem will be solved to customer satisfactions.
