Thermal Decorative Metal Carved Wall Cladding
Thermal decorative metal carved wall cladding is composed of polyurethane foam to form an insulation and heat insulation layer, and its interior is an independent closed bubble structure. The Aluminium foil pasted on the back can effectively reflect the heat source and play the role of heat insulation, heat preservation and moisture-proof. The combination of concave convex plug connection and groove type construction is very simple.
Products Description
Thermal decorative metal carved wall cladding is a building material with excellent properties such as high compression resistance, earthquake resistance, moisture resistance, waterproofing, fire prevention, sound insulation, insulation, low thermal conductivity, aesthetics, durability, energy conservation, easy construction, and environmental protection. It can be widely used for insulation and renovation of building exterior walls, interior decoration of newly built and renovated buildings, public buildings, civil buildings, and interior wall decoration of hotels, restaurants, and households
Long service time and warranty , high durable polyester paint
Let metal wall cladding panel decorating your home
Thickness 16mm , 20mm 25mm
width 380mm ,length 2000-6000mm
Galvanized steel(aluminum zinc plate steel sheet) 0.27MM /0.25MM/0.32MM
The paint is high durable polyester paint, with ANTI-UV function ,over 15 years not fade . Has stronger antioxidant and anti-corrosion properties.
High rigid thermal polyurethane foam 40KG/M3
With a thermal insulated function .Because the PU foam is high density , so it has soudproof function as well . Besides , with flame retardant
Waterproof aluminum foil paper
Aluminium foil with good ductility is used at the bottom of the board, which also has the function of waterproof and moisture-proof to prevent moisture from entering the room
Technical Specifications
|
Thickness |
16/20 mm |
Fire resistance level |
B1/B2 |
|
Width |
383mm |
Size toleranc |
-/+2mm |
|
Length |
2000mm~6000mm |
Tensile bond strength |
0.17MPA |
|
Surface steel |
Galvalume,C type |
Wind load value |
9 KPA |
|
Steel alloy composition |
Aluminum 55%,Zinc 43.5%,Silicon 1.5%,ect. |
Package |
10 pieces/carton,8pieces/carton |
|
Core material |
Polyurethane |
OEM |
Logo and panel size |
|
Closed cell rate |
90%~95% |
Container load |
20GP:1600sqm(panel length 1.82m) |
|
Panel weight |
3.5-3.7 kg/m2 |
Port |
QINGDAO |
|
Heat conductivity |
0.018-0.024 w/m*k(in theory) |
Brand |
DIBAIER |
|
Water absorption |
≤3 % |
Oxygen index |
≥26 % |
Technical Specifications
-
Thermal insulation
-
Resistant to dust and dirty
-
Extremely durable
-
Light weight
-
Saving building cost and time
-
Easy installation
-
Longer life
-
Anti-UV
-
Durable
The application case
The Thermal Decorative Metal Carved Wall Cladding is used to many engineering fields. such as municipal construction, apartment and residential buildings, office halls, villas, garden attractions, renovation of old buildings, guard posts, etc
The Waste sorting room
Waste sorting is more conducive to resource utilization and environmental protection.
The Public toilet
This one is a Pubilc toilet .It is built by meatl siding panel ,light steel frame ,insulation rock wool, OSB board . The metal wall panel not only used to toilet and waste sorting room , but also used to decor exterior wall , old house renovation , prefab house , modular house etc .
Package
Standard carton for export . 8/10pcs per box .
Length :2900/3800/3900mm
Packing width :420mm
Height :140/170mm
